The Solis S6-EH3P15K02-NV-YD-L is a 15 kW three-phase hybrid inverter designed for advanced residential and small commercial solar-plus-storage systems.
| Model Number | S6-EH3P15K02-NV-YD-L |
|---|---|
| Max. DC Input Power | 22,500 W |
| Max. DC Voltage | 600 V |
| MPPT Voltage Range | 90–520 V |
| Max. Input Current per MPPT | 16 A |
| Number of MPPTs / Strings per MPPT | 2 / 1 |
| Battery Voltage Range | 40–60 V |
| Max. Charge/Discharge Current | 135 A |
| Nominal AC Output Power | 15,000 W |
| AC Voltage / Frequency | 400 V / 50 Hz |
| Cooling Method | Passive cooling |
| Display | Color touchscreen |
| Protection Rating | IP66 |
The S6-EH3P15K02-NV-YD-L from Solis is part of the S6-EH3P series, engineered for three-phase energy storage applications using low-voltage (48V) batteries. With a 15 kW output and dual MPPTs supporting up to 32A input current, it accommodates large PV arrays with high efficiency. The inverter supports UPS-level switching for seamless backup, PV-only off-grid operation to reduce battery costs, and parallel operation of up to six units for systems up to 90 kW. It includes generator input, CAN/RS485 communication, and remote monitoring via SolisCloud. Built for durability and smart energy control, it’s ideal for energy-conscious homes and businesses.
